Product Overview

1465-V series signal generators has excellent vector modulation performance within the frequency range of 100 kHz to 67GHz. It has 1GHz internal modulation bandwidth and 2GHz external modulation real-time bandwidth, which can meet various modulation needs of wideband signals. The generator has excellent spectrum purity and output power specifications. The phase noise of 10GHz carrier@10kHz frequency offset can be reached to -126dBc/Hz, to meet high-level test needs which have strict requirements of testing signals. The generator also has excellent vector modulation accuracy and at the full frequency range the EVM is less than 1.4% (4Msps), which makes the generator be used in metrology purpose. The baseband signal generator can be set easily with flexible performance and many modulation formats. More than 20 kinds of common modulation formats are supported, such as PSK, QAM, and FSK, ASK and so on. The arbitrary wave modulation support 5 kinds of download file format, users can edit and download the waveform according to their own requirement. Thus various signal modulation can be accomplished and complex signals can be generated. Besides，the airspace capsule operation interface design and 10.1 inch high-brightness touch screen can bring a brand-new operation experience to users.

With wide frequency band and modulation bandwidth, 1465-V series signal generator can not only provide user with analog and vector modulated signal with great spectrum purity and modulation types, but also can help user edit arbitrary waves flexibly. It’s an ideal choice for performance test of components, modules, communications, and other electronic systems.



Features

  • Broadband vector signal generation

    1465-V series signal generators can provide various signal testing solutions covering 10GHz/20GHz/40GHz/50GHz/67GHz to meet user’s specific needs in different fields. Especially, 1465L-V signal generator with 100kHz～67GHz frequency range can meet test needs of most users .


  • Large Vector Modulation Bandwidth

    1465-V series signal generators can provide 1GHz internal modulation bandwidth and 2GHz external modulation bandwidth（above 3.2GHz carrier）vector signal generation function .


Drag left and right to view all the list

Model

Weight

Power Consumption

Temperature Range

Scan Mode

Scan Dwell Time

Compared

There are currently no options for this product
